Fotolink: http://pisti91.myfreeforum.org/archive/o_t__t_70__start_800__index.html
| 75 TR | Gabs-w | IGA |
|
| | CODE + VKM | 31 75 TCDD | Türkiye Cumhuriyeti Devlet Demiryollari | ||
| | UIC Nr | 31 75 1810 001 - 1810 101 | Gabs-w Gabns | ||
| | Ex Nr |
| | 20. L/P min | -- | cm | | 30. DB/SSH | 400 | cm | | 40. BR AUT | SW-GP-A | |
| | 21. L/P max | 2170 | cm | | 31. DH/ESH | 215 | cm | | 41. BR MAN | Hbr/ps | |
| | 22. AXT/BCA | 1666 | cm | | 32. FLH | 120 | cm | | 42. | ||
| | 23. BAXT | 180 | cm | | 33. GLW | 90 | t | | 43. Y PROD | ? | |
| | 24. IL | 2046 | cm | | 34. TARE | 28,5 | t | | 44. Y + | ? | |
| | 25. IB | 255 | cm | | 35. ABCD max | 61,5 | t | | 45. Y OBS | 2007 - 2014 | |
| | 26. BFL | 52,0 | m2 | | 36. @ KM/H | S | km/h | | 46. | ||
| | 27. IHS | 215 | cm | | 37. KM/H max | S | km/h | | 47. DRW | LINK | |
| | 28. IHM | ? | cm | | 38. @ ABCD | 61,5 | t | | 48. FOTO | LINK | |
| | 29. RF | 1370 | hl | | 39. 120 km/h | -- | t | | 49. MORE INFO | >> LINK << |
Rem:
Tüdemsas: http://www.tudemsas.gov.tr/tudemsas/tr/HTML/yuk_vagonlari/20091213_175611_1_1_1.html
Fotos: http://www.forumtrenuri.com/t169p860-vagoane-marfa
|
